Total Weight

50 g

Option – other Power source

4V – 30V

Passive consumption

100 mW

Consumption in radar active mode

600 mW

Frequency band

K-Band 24GHz

Bandwidth

Modulation

FMCW

Vertical Speed Detection

0,4-1000 m/sec

Horizontal & Vertical Field of View

30 degree * 20 degree

Measuring range

1m-25 m over following conditions:

• Approach Velocity from 0,4-1000 m/sec

• Approach Angles from 15° to 90°

• Target Reflectivity range +5,5dB to -17 dB

Target surfaces Reflectivity +5,5dB to -17 dB

• Soil (Wet and Dry)
• Water
• Concrete
• Forest (Dense Foliage)
• Desert sand

ALL WEATHER CONDITIONS:

• Rain
• Fog
• Hurricane
• Heavy snow
• Forest leaves

Min Operational Altitude

1 m

Max Operational Altitude

25 m

Measurement period (Scan rate)

300  micro seconds

Altitude precision at 10 m/sec

1 cm

Jamming resistance

Еncoded digital signal with frequency hopping

Maximum output current

3.5 A @ 3.5V

Immunity to interferences and clutter-

No early burst

a) Digital radar filters

b) Radar sensor activation at preset time AFTER the maximum height is reached

(top of the trajectory zero g)

Supported Interface

UART(Universal Asynchronous Receiver/Transmitter), CAN Controller Area Network

Update Rate

UART 82Hz, CAN 86Hz

Connector

4PIN GPIO/JST. SPI - Serial Peripheral Interface

Operation temperature

-40C to +60 C

Storage temperature

-60C to +85 C

Environmental Conditions:

IP67 Dust: No ingress. Water: 30 mins immersion at 1m depth

Warranty

12 Months

Materials

RoHS complaint

Export

ITAR free. Export licence not required
